1. Automatic Hybrid Power Input(Solar, AC/Diesel/Battery Power)
2. Automatic MPPT Function to Identify the VOC and VMP of Solar Panel
3. IP65 Waterproof
4. GPRS SMS Control/Monitoring
5. Protection:
.Solar DC Input Anti-Reverse
.AC Input/Output Phase lost(3Phase)
.AC Output Short Circuit
.AC Output Unbalance (3Phase)
.Pump Dry Run (unload water)By Sensor/Software
.Water Over Flow of Tank
.Solar Low Power
.Against Lighting
6. Variable Frequency Drive the AC Pump (1Hz ~ 50/60Hz)
Call now： +86 574-63752220
| Model |
Rated Power (KW) |
Solar Panel Voltage (Vmp Min-Voc Max) |
Solar Panel Voltage (Recommend Vmp) |
Hybrid AC Power |
Hybrid Battery Power Voltage |
Inside Booster |
Pump Phase |
Pump Voltage |
Pump Frequency |
Pump Power |
| HSPL/H750L | 0.75 | 80~450 | ≥100V |
Single or Triphase 220V,50/60Hz |
312V | Y |
Triphase or Single Phase (compatibility) |
220/240V | 50/60Hz | < 750W |
| HSPH1500L | 1.5 | 100~450 | ≥150 | < 1500W | ||||||
| HSPH2200L | 2.2 | 200-450 | ≥300(Only Solar) | N | < 2200W | |||||
| HSPH2200H | 2.2 | 400-780 |
≥500(Only Solar) ≥560(Hybrid Power) |
Triphase 380/400/440V, 50/60Hz |
480V | N | Triphase | 380/400/440V | < 2200W | |
| HSPH3700H | 3.7 | < 3700W | ||||||||
| HSPH5500H | 5.5 | < 5500W | ||||||||
| HSPH7500H | 7.5 | < 7500W | ||||||||
| HSPH11KH | 11 | < 11KW | ||||||||
| HSPH15KH | 15 | < 15KW | ||||||||
| HSPH18KH | 18 | < 18KW | ||||||||
| HSPH22KH | 22 | < 22KW | ||||||||
| HSPH30KH | 30 | < 30KW | ||||||||
| HSPH37KH | 37 | < 37KW | ||||||||
| HSPH45KH | 45 | < 45KW | ||||||||
| HSPH55KH | 55 | < 55KW | ||||||||
| HSPH75KH | 75 | < 75KW | ||||||||
| HSPH100KH | 100 | < 100KW | ||||||||
| HSPH150KH | 150 | < 150KW |
